Part Number

Dia. ØA (mm)

Dim. B (mm)

Dim. C (mm)

Thread ØD (mm)

Dia. ØE (mm)

Dim. F (mm)

Dim. G (mm)

Dia. ØH (mm)

Ref. Number

ALP-22181815

22

46

45

18 X 1.5

18

130

5

37

09312

ALP-22202015

22

50

40

20 X 1.5

20

130

5

38

05199

ALP-22222215

22

50

40

22 X 1.5

22

140

14

38

00040

ALP-22282215

22

50

40

22 X 1.5

28

140

14

38

00036

ALP-22252215

22

60

40

22 X 1.5

25

150

20

32

ALP-25252215

25

60

40

22 X 1.5

25

150

20

40

ALP-25282215

25

60

40

22 X 1.5

28

150

20

38

ALP-2830302

28

50

30

30 X 2

30

155

50

50

ALP-28222215

28

60

45

22 X 1.5

22

150

14

44

00041

ALP-28242215

28

55

45

22 X 1.5

24

150

14

42

09313

ALP-28242415

28

55

45

24 X 1.5

24

150

15

43

09314

ALP-28282215

28

60

40

22 X 1.5

28

150

20

43

00037

ALP-28282715

28

55

45

27 X 1.5

28

150

14

42

09315

ALP-28272715

28

58

48

27 X 1.5

27

147

10

43

ALP-36272715

36.5

61

60

27 X 1.5

27

165

11

50

Part Number

Dia. ØA (mm)

Dia. ØA1
(mm)

Dim. B (mm)

Dim. C (mm)

Thread ØD (mm)

Dia. ØE (mm)

Dim. F (mm)

Ref. Number

LLPDM-2822242

22.00

28

58

90

24 X 2

12

195

08019

LLPDM-2822273

22.00

28

58

90

27 X 3

12

195

00039
